STATCOM – Static Synchronous Compensation

Modern power grids face increasing challenges in maintaining stable and reliable voltage regulation amidst growing power demand and the integration of renewable energy. Changes in load and generation can cause voltage fluctuations, harmonics, and reactive power issues that threaten grid stability and power quality.

STATCOMs enhance grid stability with dynamic power system compensation

As rapid-response shunt devices with advanced capabilities for voltage control, reactive power compensation, and active power flow management, STATCOMs will play an increasingly vital role in optimizing grid performance and stability.

Advantages of STATCOM

STATCOMs provide several major advantages to electrical grids, including:

Improved Grid Stability

STATCOMs help maintain system stability during transient events by providing fast-acting, reactive power compensation. This allows for better control over power system oscillations and improves transient stability.

Increased Power Flow Control

These systems can control both active and reactive power flow in transmission lines by adjusting the magnitude and phase angle of the output voltage. This enhances the transmission line ability to transfer power in weakly interconnected systems.

Reduced Transmission Losses

By optimizing reactive power flow, STATCOMs help reduce transmission losses and improve transmission efficiency.

Improved Voltage Profile and Power Quality

STATCOMs regulate voltage at the connection point, correcting for sags, swells, and transients. This results in improved voltage profile and power quality for sensitive industrial loads.


Proper selection and configuration of equipment can offer substantial benefits

Renewable Generation and Transmission

Power factor control and voltage regulation are indispensable for grid stability in renewable generation and transmission.

  • Voltage stabilization
  • Increased transient voltage stability
  • Power oscillation mitigation
  • Reactive power compensation
  • Losses reduction
  • Increase line capacity

Steel Industry

A steady voltage and low harmonic content increase productivity and reduce costs.

  • Enhance Electric Arc Furnace productivity through voltage stabilization
  • Complimentary solution to assist green steel goals.
  • Avoid voltage sags through dynamic reactive power compensation
  • Reduce energy and losses
  • Improve power quality and comply with connection requirements

Heavy Industry

Load evolution demands faster and more efficient solutions to avoid downtime and increase equipment life.

  • Power factor compensation
  • Harmonic mitigation
  • Energy cost reduction
  • Reduced outages
  • Increased productivity
  • Comply with grid code requirements

STATCOMs: A Next-Generation Technology for Optimizing Modern Power Grid Resilience and Performance

STATCOMs are versatile and multifunctional devices that provide numerous grid stabilization and voltage regulation capabilities within one compact package. The advanced power electronics and control systems within a STATCOM essentially act as a shock absorber to smooth out voltage fluctuations, enhance grid stability, and maintain reliable electricity supply during dynamic operating conditions.

As power grids transition to higher levels of renewable generation and more complex operations, flexible grid assets like STATCOMs will become increasingly critical for ensuring grid resilience, reliability, and effective integration of new technologies. With continued development of power electronic components and control capabilities, STATCOMs are poised to be an essential grid asset for enabling stable and robust electricity delivery amidst the evolving modern power landscape.

An Image Illustrating a STATCOM set-up

STATCOM: Empowering Decarbonization through Grid Stability and Renewable Integration

The Static Synchronous Compensator (STATCOM) plays a pivotal role in the ongoing global effort towards decarbonization. As renewable energy sources like solar and wind power become increasingly integrated into the electrical grid, their intermittent and variable nature poses challenges to grid stability. STATCOM, a flexible and fast-acting power electronic device, provides dynamic voltage support and reactive power compensation, enhancing grid reliability and enabling the seamless integration of renewable energy.

By mitigating voltage fluctuations and maintaining grid voltage within desired limits, STATCOM facilitates optimal operation of renewable sources, reduces curtailment, and minimizes the need for fossil-fuel-based backup generation. Consequently, the deployment of STATCOM technology not only accelerates the transition to a cleaner energy mix but also promotes a more resilient and sustainable energy infrastructure essential for successful decarbonization strategies.

Empowering Green Steel Production: The Crucial Role of STATCOM Solutions

STATCOM solutions play a pivotal role in bolstering the steel industry’s endeavors to produce environmentally friendly green steel. With the increasing integration of renewable generation into the grid, STATCOMs are poised to become the primary solution in many cases owing to their rapid reactive power support capabilities. This is particularly relevant when steel loads implement projects involving both load and generation behind the meter, as STATCOMs guarantee compliance with interconnection requirements. As renewable energy gains traction in steel production, STATCOM technology stands out as a cornerstone, ensuring sustainable and compliant practices while driving the industry closer to its green steel objectives.
